『徵求 MC230/330 說明書』
請問大大們
誰又FUTABA MC330CR 的說明書
小弟買一個中古ㄉ
不會設定....苦惱阿
希望各位大大幫忙
肛溫蛤~

要設什麼? 我記得. 330很簡單.

1. 回復內定 (有後退) , 先關電, 再按著按鈕不放, 再開電.

2. 設油門中點及行程: 先開發射機(中點位置調好).
按一次按鈕. LED 閃一下滅.
發射機油門最大, 再按一次按鈕, LED 閃 2 次
發射機煞車位置, 再按一次按鈕, 完成.

大丐醬子.


MC330CR 很爆貴,也不知貴在那, OEM 的 ACME 也不過330CR一半的價格 ,同樣也是 Futaxxx 正代工
貼個看看.

此主題相關圖片如下：

Turn on the power in transmitter -> amp order.

Neutral point setting
- Transmitter throttle on Neutral state
- press the pushbotton switch (0.5 sec. or longer) (confirmation beep sounds)
-LED continuous single blink

High point setting
- Transmitter throttle on full high state
- press the pushbotton switch (confirmation beep sounds)
-LED continuous double blink

Brake MAX point setting
- Transmitter throttle on full brake state
- press the pushbotton switch (confirmation beep sounds)
- if the LED goes out, setting is complete

Since tehe data is read at the end of setting of all points, the point cannot be set independently
If the AMP power was turned off during setting, the setting points cannot be memorized (previous settings are retained)

The confirmation beep sounds only when the motor was connected

If the LED does not go off but blinks rapidly, setting was not performed normally. Repeat setting from "Neutral point setting"

Reverse function cancellation
While pressing the pushbutton switch, set the power switch to ON.

When desired, you can enable the cancelled reveerse function by repeating the operation shown at above. (The reverse function is switched alternately)

HEY GAYS
THANK YOU VERY MUCH.....

啊!
再一個問題
這可以難到幾"T"阿

甩尾要幾"T"呢

330cr 13T, OEM的都一樣!!

你也玩甩尾喔.. 我好久沒玩哩., 用23T YOKOMO SR很好甩. 540原車馬達也有人甩的很爽..


PS : MC330CR 說明書 我忘了在這裡下載到啦 http://www.futaba-rc.com/manuals/futm0932-manual.pdf

祝好運~~~~~~~~~~~~~~~~~~~~~~~

OEM 的 ACME上那買...高雄怎沒看過....價格?

ACME B1006 這個東東..目前台灣很少量有進吧..

這個 ACEM 恐怕還沒有倫知道吧?!! 他就是大陸 深圳頂點實業公司的產品...

我相信, 以大陸這樣的環境,要稿出一顆 CLONE 版本的 MC330 是超容易滴., 當然價格就..
